APARATE DE AER CONDITIONAT DE TIP CASETA - pompa de caldura
|
Unitatea Externa
|
Comanda
|
Ansamblu
|
Unitatea Interna
|
[1] [2]
| Unitate Interna | PLA-P1,6 | PLA-P2 | PLA-P2,5 | PLA-P3 |
| Unitate Externa | PUH-P1,6 | PUH-P2 | PUH-P2,5 | PUH-P3 |
| Capacitate Racire | 4.4 KW | 5.4 KW | 6.3 KW | 7.8 KW |
| Capacitate Incalzire | 5 KW | 6.3 KW | 7.4 KW | 9.3 KW |
| Consum Incalzire | 1.9 KW | 2.4 KW | 2.6 KW | 3.5 KW |
| Consum Racire | 1.8 KW | 2.4 KW | 2.6 KW | 3.4 KW |
| Debit Aer Interior | 780/960 | 780/960 | 840/1020 | 900/1200 |
| Dimensiune Unit. Int. | 660/660/298 mm | 660/660/298 mm | 660/660/298 mm | 840/840/258 mm |
| Dimensiune Unit. Ext. | 900/350/650 mm | 900/350/855 mm | 900/350/855 mm | 900/350/855 mm |
| Nivel Zgomot Unit. Int. | 32/37 dB | 32/37 dB | 35/39,5 dB | 28/34 dB |
| Nivel Zgomot Unit. Ext. | 46 dB | 48 dB | 48 dB | 49 dB |
|
|
|
