APARATE DE AER CONDITIONAT DE TIP COLOANA - pompa de caldura
|
Unitatea Externa
|
Comanda
|
Ansamblu
|
Unitatea Interna
|
| Unitate Interna | PCA-P3 | PCA-P4 | PCA-P5 | PCA-P6 |
| Unitate Externa | PUH-P3 | PUH-P4 | PUH-P5 | PUH-P6 |
| Capacitate Racire | 7.7 KW | 9.7 KW | 12.4 KW | 14 KW |
| Capacitate Incalzire | 9.3 KW | 10.9 KW | 14.6 KW | 17.1 KW |
| Consum Incalzire | 3.5 KW | 3.8 KW | 5.1 KW | 6.3 KW |
| Consum Racire | 3.4 KW | 3.6 KW | 4.9 KW | 5.9 KW |
| Debit Aer Interior | 900/1080 | 1440/1860 | 1560/1980 | 1620/2100 |
| Dimensiune Unit. Int. | 600/270/1900 mm | 600/350/1900 mm | 600/350/1900 mm | 600/350/1900 mm |
| Dimensiune Unit. Ext. | 900/350/855 mm | 900/350/1260 mm | 1050/350/1260 mm | 1050/350/1260 mm |
| Nivel Zgomot Unit. Int. | 40/45 dB | 44/49 dB | 46/51 dB | 47/52 dB |
| Nivel Zgomot Unit. Ext. | 49 dB | 51 dB | 53 dB | 55 dB |
|
|
|
